AFTEK develops HMI Platform with Touch screen panel for Industrial applications

[Oct 12, 2010]

Aftek Ltd, a leading System developer in the market, today introduced a resistive touch screen enabled HMI platform supporting a variety of operating systems, powered by a 32-bit processor high performance Application processor. This platform is coupled with a LCD touch screen display ranging in size from 4.3-inch to 10-inch up to 2048 x 2048 resolution. The HMI platform is highly configurable and offers 128 MB of DDR2 SDRAM, 512 MB of NAND Flash, a variety of I/O ports, USB and Ethernet connectivity along with an SD expansion slot.

Continuing Aftek's tradition of offering cost-effective development and fast output to market, the HMI flash board is ideally suited for tablet-designed HMI panels. It can be readily used in the following application areas: Factory Automation, Process Automation, Packaging Industry, Water / Effluent Treatment, Injection Molding and more.

The flash board is powered by an 32-bit processor and be configured to run on a variety of operating systems.

Such as Windows CE 6.0, Linux 2.6 and QNX. The board comes with a TFT LCD touch screen offering WVGA resolution and is available in 7'' and with 400 cd/m2.The display offers LED backlight for easy readability and touch pad for fast navigation.

The HMI platform is supported with 128 MB of DDR2 SDRAM and 256 MB of NAND Flash storage, along with an SD expansion slot. It has built-in RTC and runs on 12 - 24 V DC. It also offers Ethernet 10 / 100 connectivity, one isolated RS485 port, two RS232 port, one USB 2.0 HS Host, one USB 2.0 HS device and one parallel printer port. It also provides multiple isolated digital input output ports.

The system offers highly modular design and can be configured according to specific requirements. Many optional I/O ports can be added / removed from the base flash board to suit a particular application area, making it a truly versatile HMI solution.
